Rolec Ultracharge

UltraCharge models 30 and 80 provide a compact, robust, and cost-effective DC rapid charging solution for destinations with limited available space. This cost-effectiveness makes them a prudent and smart investment for businesses. The slim and robust design also maximises space limitations while still being easy to install, maintain, and service.

UltraCharge models 160 and 240 offer an intelligent, modular, and scalable DC ultra-rapid charger. This scalability, allowing for upgrades in modules of 20kW up to 240kW, ensures that your charging solution can adapt to future needs. It is a cost-effective, robust solution for public, fleet, and highway infrastructure deployment.

These chargers, available in several standard power configurations, offer the convenience of charging two vehicles simultaneously. This feature, along with their ease of installation, maintenance, and service, and their conformity to ISO 15118 Plug & Charge and PAS 1899 accessible charging standards, makes them a highly efficient choice for businesses and infrastructure developers.

Features:

• Plug & charge, mobile app, or RFID controlled charging
• Offers 2x DC charging outputs
• Different models offer different charging speeds of 30kW - 240kW
• Upgradeable power modules
• OCPP 1.6 compliant (OCPP 2.0.1 upgradable)
• Over-the-air firmware / software updates
• Intelligent dynamic power sharing
• Supports static and dynamic load management
• 15" HD user interface touch screen with advertising capability
• 4G / Ethernet connectivity
• 96% Peak efficiency
• Ultrawide constant power output voltage range 300V – 1000V
• Under/overvoltage, DC overcurrent, over-temp & surge protection
• Optional 7m cables also available (6.5m external)
• Optional cable management system
• Optional RFID / NFC / contactless card payment terminal
• Conforms with PAS 1899 accessible charging standard
• Strong and durable IP55 / IK10 rated
• Stocked in the UK by Rolec EV
